    CaseIH 4240

    CaseIH 4240 tractor photo
    1994 - 1997   4200 Utility Series
    Utility tractor
    Previous model:CaseIH 995
    Next model:CaseIH CX100
    Smaller:CaseIH 4230






    Production:

    Manufacturer:CaseIH
    Factory:Doncaster, England
    Original price (USD):$32,000 (1997)


    CaseIH 4240 Engine:

       Case 4.4L 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:20 gal [75.7 L] (ROPS)
     29.6 gal [112.0 L] (cab)
    Hydraulic system:9 gal [34.1 L] (2WD)
     9.7 gal [36.7 L] (cab)


    3-Point Hitch:

    Rear Type:II
    Control:draft and position control
    Rear lift:3,665 lbs [1662 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Clutch:hydraulic wet disc
    Rear RPMs:540
     540/1000 (optional)


    Dimensions & Tires:

    Wheelbase:88.7 inches [225 cm] (2WD)
     88 inches [223 cm] (4WD)
    Weight:6687 to 7395 pounds
    Front tire:7.50-16
    Rear tire:16.9-28 (2WD)
    full dimensions and tires ...


    4240 Serial Numbers:


    - Serial numbers unknown -



    CaseIH 4240 Power:

    Engine (gross):104 hp [77.6 kW]
    Engine (net):99 hp [73.8 kW]
    PTO (claimed):85 hp [63.4 kW]


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Differential lock:mechanical (ROPS)
     electro-hydraulic (cab)
    Steering:hydrostatic power
    Brakes:hydraulic wet disc
    Cab:Two-post ROPS. Cab optional.


    Hydraulics:

    Type:open center
    Capacity:9 gal [34.1 L] (2WD)
     9.7 gal [36.7 L] (cab)
    Pressure:2500 psi [172.4 bar]
    Valves:0 to 3
    Total flow:16.1 gpm [60.9 lpm]
     18.4 gpm [69.6 lpm] (optional)


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:45
     65 (cab, ROPS opt.)


    Battery:

    Number:1
    Cold-cranking amps:650
     810 (optional)
    Volts:12
