CaseIH 1594
|
|
| Production | |
| Manufacturer | CaseIH |
| Utility tractor | |
| Original price | $26,000 (1988) |
| CaseIH 1594 Engine | |
| Case 5.4L 6-cyl diesel | |
| Fuel tank | 36 gal 136.3 L |
 Engine details ... | |
| CaseIH 1594 Transmissions | |
| 12-speed synchromesh | |
| 12-speed partial power shift | |
 Transmission details ... |
| CaseIH 1594 Power | |
| Engine | 97 hp 72.3 kW |
| Drawbar (claimed) | 74 hp 55.2 kW |
| PTO (claimed) | 86 hp 64.1 kW |
| Drawbar (tested) | 72.17 hp 53.8 kW |
| PTO (tested) | 85.90 hp 64.1 kW |
 Performance test details ... | |
| Mechanical | |
| Drive | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Steering | hydrostatic power |
| Differential hydraulic wet disc brakes | |
| ROPS or cab. | |
| Photos | |
 | |
 CaseIH 1594 photos... | |
| Hydraulics | |
| Type | open center |
| Pressure | 2600 psi 179.3 bar |
| Valves | 2 |
| Total flow | 10.5 gpm 39.7 lpm |
| 20.1 gpm (tandem) 76.1 lpm | |
| Steering flow | 7.7 gpm 29.1 lpm |
| Steering press. | 1850 psi 127.6 bar |
| Tractor hitch | |
| Rear Type | II |
| Rear lift (at ends) | 7,440 lbs 3374 kg |
| Rear lift (at 24"/610mm) | 6,290 lbs 2853 kg |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Rear PTO Type | 540/1000 |
| Dimensions & Tires | |
| Wheelbase | 100 inches 254 cm |
| Weight | 9,290 lbs 4213 kg |
| Front tire | 10.00-16 |
| Rear tire | 16.9-38 |
 Full dimensions and tires ... | |
| 1594 Serial Numbers | |
| Location: | On right side of main frame |
| 1985 | 11526001 |
| 1986 | 11526518 |
| 1987 | 11527297 |
| 1988 | 11528442 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Charging system | alternator |
| Charging amps | 45 |
| 65 (heavy duty) | |
| Battery CCA | 420 |
| 550 (heavy duty) | |
| Battery volts | 12 |
| Battery AH | 96 |
| 128 (heavy duty) | |
| References | |
 | |
| 1985 Farm Equipment Buyer's Guide published by CaseIH |
