Tractors > CaseIH > C90

CaseIH C90 - transmission

CaseIH C90 tractor photo
1998 - 2002   CX Utility Series
Utility tractor
Series next:CaseIH C100
Series back:CaseIH C80
more CaseIH C90 specifications...






Transmission:

Gears:8 forward and 4 reverse
Clutch:12-inch dry disc
Oil capacity:36 qts [34.1 L] (2WD)
 38.6 qts [36.5 L] (4WD)


Transmission:

Type:partial power shift
Gears:16 forward and 8 reverse
Clutch:12-inch dry disc
Oil capacity:36 qts [34.1 L] (2WD)
 38.6 qts [36.5 L] (4WD)
Speeds:
C90  partial power shift speeds


Transmission:

Gears:8 forward and reverse
Oil capacity:36 qts [34.1 L] (2WD)
 38.6 qts [36.5 L] (4WD)


Transmission:

Type:creeper
Gears:16 forward and 8 reverse
