CaseIH CX70


CaseIH CX70 tractor photo
1998 - 2002
CX Utility Series
Utility tractor
Series map:
CX60
CX70
CX80
64.0hp
73.0hp
84.0hp
Production
ManufacturerCaseIH
Utility tractor
Built in Doncaster, England
Original price$27,000 (1999)
Variants
CX70deluxe model
C70basic model
CaseIH CX70 Engine
Perkins 4.2L 4-cyl diesel
Engine details ...
CaseIH CX70 Transmissions
8-speed synchro shuttle
16-speed partial power shift
24-speed creeper
Transmission details ...
CaseIH CX70 Power
Engine (gross)73 hp
54.4 kW
Engine (net)66 hp
49.2 kW
PTO (claimed)58 hp
43.3 kW
Drawbar (tested)50.2 hp
37.4 kW
PTO (tested)59.7 hp
44.5 kW
Performance test details ...
Mechanical
Drive4x2 2WD
 4x4 MFWD 4WD (optional)
Differential lockelectro-hydraulic
Steeringhydrostatic power
Differential hydraulic wet disc brakes
Two-post ROPS with flat platform. Optional cab with air-conditioning.
Photos
No photos of the CaseIH CX70 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel42 gal
159.0 L
Hydraulic system9.1 gal (2WD)
34.4 L
 9.8 gal (4WD)
37.1 L
Hydraulics
Typeopen center
Capacity9.1 gal (2WD)
34.4 L
 9.8 gal (4WD)
37.1 L
Pressure2500 psi
172.4 bar
Valves0 to 3
Pump flow15.7 gpm
59.4 lpm
Total flow24.2 gpm (total)
91.6 lpm
 15.7 gpm (main pump)
59.4 lpm
 8.5 gpm (lube pump)
32.2 lpm
Tractor hitch
Rear TypeII/I
Controlelectronic upper link
Rear lift3,665 lbs
1662 kg
 5,097 lbs (optional)
2311 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchhydraulic wet disc
Rear RPM540
 540/1000 (optional dual shaft)
Dimensions & Tires
Wheelbase89.1 inches (2WD)
226 cm
 92.7 inches (4WD)
235 cm
Weight7396 to 8466 pounds
Front tire7.50-16
Rear tire16.9-30
Full dimensions and tires ...
CX70 Serial Numbers
Location:Near the tractor steering column on right side.
1998JJE1000056
1999JJE1008492
2000JJE1013490
2001JJE1017672
2002JJE1019985

FAQ: How to read a serial number table.
Electrical
Groundnegative
Charging systemalternator
Charging amps65
Battery CCA650
 810 (optional)
Battery volts12
References
CX70 references literature
CX Series Tractors published in 1997, by CaseIH
