CaseIH C60
|
|
| Production | |
| Manufacturer: | CaseIH |
| Type: | Utility tractor |
| Factory: | Doncaster, England |
| Original price: | $22,400 (1999) |
| CaseIH C60 Power | |
| Engine (gross): | 64 hp 47.7 kW |
| Engine (net): | 60 hp 44.7 kW |
| PTO (claimed): | 50 hp 37.3 kW |
| Drawbar (tested): | 48.4 hp 36.1 kW |
| PTO (tested): | 56.5 hp 42.1 kW |
| CaseIH C60 Engine | |
| Perkins 2.7L 3-cyl diesel | |
 Engine details ... |
| Mechanical | |
| Chassis: | 4x2 2WD |
| 4x4 MFWD 4WD (optional) | |
| Differential lock: | mechanical |
| Steering: | hydrostatic power |
| Brakes: | differential hydraulic wet disc |
| Cab: | Two-post ROPS with straddle platform. |
| Transmissions: | 8-speed |
| 16-speed partial power shift | |
| 16-speed creeper | |
 Transmission details ... | |
| Photos | |
| No photos of the CaseIH C60 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Fuel: | 20 gal 75.7 L |
| Hydraulic system: | 9 gal 34.1 L (2WD) |
| 9.7 gal 36.7 L (4WD) | |
| Hydraulics | |
| Type: | open center |
| Capacity: | 9 gal 34.1 L (2WD) |
| 9.7 gal 36.7 L (4WD) | |
| Pressure: | 2500 psi 172.4 bar |
| Valves: | 0 to 3 |
| Pump flow: | 12.7 gpm 48.1 lpm |
| Total flow: | 15.7 gpm 59.4 lpm |
| Tractor hitch | |
| Rear Type: | II/I |
| Control: | mechanical |
| Rear lift: | 3,665 lbs 1662 kg |
| 5,097 lbs 2311 kg (optional) | |
| Power Take-off (PTO) | |
| Rear PTO: | independent |
| Clutch: | hydraulic wet disc |
| Rear RPM: | 540 |
| 540/1000 (optional dual shaft) | |
| Dimensions & Tires | |
| Wheelbase: | 80.9 inches 205 cm (2WD) |
| 83.3 inches 211 cm (4WD) | |
| Weight: | 5357 to 7605 pounds |
| Front tire: | 7.50-16 |
| Rear tire: | 14.9-28 |
 Full dimensions and tires ... | |
| C60 Serial Numbers | |
| Location: | Near the tractor steering column on right side. |
| 1998: | JJE1000056 |
| 1999: | JJE1008492 |
| 2000: | JJE1013490 |
| 2001: | JJE1017672 |
| 2002: | JJE1019985 |
| Electrical | |
| Ground: | negative |
| Charging system: | alternator |
| Charging amps: | 65 |
| Battery CCA: | 650 |
| 810 (optional) | |
| Battery volts: | 12 |
