Tractors > Challenger > 75D

Challenger 75D



Challenger 75D tractor photo
1996 - 1997
Agricultural Crawler tractor
Series map:
65D
75D
85D
300.0hp
330.0hp
370.0hp
Production
ManufacturerChallenger (a part of Caterpillar)
Agricultural Crawler tractor
Original price was $144,000 in 1997
Challenger 75D Engine
Caterpillar 10.3L 6-cyl diesel
Engine details ...
Challenger 75D Transmission
10-speed full power shift
Transmission details ...
Challenger 75D Power
Engine (gross)330 hp
246.1 kW
Drawbar (claimed)240 hp
179.0 kW
PTO (claimed)285 hp
212.5 kW
Drawbar (tested)254.52 hp
189.8 kW
PTO (tested)300.58 hp
224.1 kW
Performance test details ...
Mechanical
Drivecrawler
Steeringhydrostatic differential steering
Hydraulic wet disc brakes
Cab standard with air-conditioning.
Photos
No photos of the Challenger 75D are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel203 gal
768.4 L
Hydraulic system29 gal
109.8 L
Hydraulics
Typeclosed-center pressure-compensated
Capacity29 gal
109.8 L
Pressure2750 psi
189.6 bar
Valves4
Pump flow27 gpm
102.2 lpm
 35 gpmOptOptional
132.5 lpm
Tractor hitch
Rear TypeIV/III
Controlposition and draft control
Rear lift12300 lbs
5579 kg
Power Take-off (PTO)
Rear PTOindependent
Rear PTO Type1000 (1.75)
Engine RPM1000@2050
Dimensions & Tracks
Wheelbase107 inches
271 cm
Weight35720 lbs
16202 kg
25-inch tracks
Full dimensions and tracks ...
Electrical
Groundnegative
Charging systemalternator
Charging amps145
Batteries2
Battery CCA900
Battery volts12
References
75D references literature
Challenger 75D Agricultural Tractor published in 1996, by Caterpillar
Challenger 85D Agricultural Tractor published in 1996, by Caterpillar
