Tractors > Challenger > 65B

Challenger 65B

Challenger 65B tractor photo
1991 - 1992
Agricultural Crawler tractor
Previous model:Challenger 65
Next model:Challenger 65C






Production:

Manufacturer:Caterpillar


Challenger 65B Engine:

   Caterpillar 10.5L 6-cyl diesel
full engine details ...


Capacity:

Fuel:220 gal [832.7 L]


3-Point Hitch:

Rear Type:III/IV
Rear lift:11,370 lbs [5157 kg]


Power Take-off (PTO):

Rear RPM:1000


Dimensions & Tires:

Wheelbase:106 inches [269 cm]
Weight:34,030 lbs [15436 kg]
Front tire:tracks
Rear tire:tracks
full dimensions and tires ...


65B Serial Numbers:


- Serial numbers unknown -



Challenger 65B Power:

Engine:285 hp [212.5 kW]
Drawbar (tested):220.32 hp [164.3 kW]
PTO (tested):257.20 hp [191.8 kW]
power test details ...


Mechanical:

Chassis:crawler
Steering:hydrostatic differential steering
Brakes:hydraulic caliper disc
Cab:Cab standard


Hydraulics:

Type:closed
Valves:4
Pump flow:26 gpm [98.4 lpm]


Battery:

Volts:12
