    Massey Ferguson 4840

    Massey Ferguson 4840 tractor photo
    1978 - 1983   4000 4WD Series
    Four-wheel Drive (4WD) tractor
    Previous model:Massey Ferguson 1505
    Larger:Massey Ferguson 4880
    Smaller:Massey Ferguson 4800






    Production:

    Manufacturer:Massey Ferguson
    Original price (USD):$98,000 (1983)


    Massey Ferguson 4840 Engine:

       Cummins 14.8L 8-cyl diesel
    full engine details ...


    Capacity:

    Fuel:190 gal [719.1 L]
    Steering:96 qts [90.9 L]
    Front axle:42 qts [39.7 L]
    Rear axle:84 qts [79.5 L]


    3-Point Hitch:

    Rear Type:IV
    Control:position control with electronic lower link sensing
    Rear lift (at 24"/610mm):11,000 lbs [4989 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:1000 (1.75)
    Engine RPM:1000@2350


    Dimensions & Tires:

    Wheelbase:137 inches [347 cm]
    Weight:27000 to 30920 pounds
    Front tire:23.1-34
    Rear tire:23.1-34
    full dimensions and tires ...


    4840 Serial Numbers:

    Location:Rear, right-side of cab
    1978: 9D001001
    1979: 9D001031
    1980: 9D002102
    1981: 9D002752
    1982: 9D003515
    1983: 9D003897

    how to read serial numbers...



    Massey Ferguson 4840 Power:

    Engine (net):265 hp [197.6 kW]
    Drawbar (claimed):170 hp [126.8 kW]
    PTO (claimed):211 hp [157.3 kW]
    Drawbar (tested):179.65 hp [134.0 kW]
    PTO (tested):210.67 hp [157.1 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 articulated 4WD
    Steering:articulated hydrostatic power
    Brakes:hydraulic caliper
    Cab:Cab standard with heat and air-conditioning. Optional AM/FM 8-track stereo.


    Hydraulics:

    Type:open center
    Valves:3 to 4
    Pump flow:16 gpm [60.6 lpm] (transmission)
     16 gpm [60.6 lpm] (lift)
     28 gpm [106.0 lpm] (auxiliary)
    Total flow:60 gpm [227.1 lpm]
    Steering cap.:96 qts [90.9 L]


    Electrical:

    Ground:negative
    Charging system:alternator
    Charging amps:60


    Battery:

    Number:4
    Volts:12
