Massey Ferguson 4263
|
|
| Production | |
| Manufacturer | Massey Ferguson |
| Utility tractor | |
| Built in Coventry, England | |
| Original price was $35,600 in 1999 | |
| Massey Ferguson 4263 Engine | |
| Perkins 6.0L 6-cyl diesel | |
 Engine details ... |
| Massey Ferguson 4263 Transmissions | |
| 8-speed nonsynchronized gear | |
| 12-speed partially synchronized | |
| 12-speed synchronized shuttle | |
 Transmission details ... |
| Massey Ferguson 4263 Power | |
| Engine (net) | 100 hp 74.6 kW |
| PTO (claimed) | 90 hp 67.1 kW |
| Drawbar (tested) | 78.3 hp 58.4 kW |
| PTO (tested) | 94.9 hp 70.8 kW |
 Performance test details ... | |
| Mechanical | |
| Two- or four-wheel drive | |
| Final drives | outboard planetary |
| Power steering | |
| Independent hydraulic wet disc brakes | |
| Two-post folding ROPS. Cab optional with air-conditioning. | |
| Photos | |
| No photos of the Massey Ferguson 4263 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer. | |
| Capacity | |
| Cab Fuel | 38 gal 143.8 L |
| ROPS Fuel | 34.3 gal 129.8 L |
| 16.4 gal (cab opt.) 62.1 L | |
| 18.5 gal (ROPS opt.) 70.0 L | |
| Hydraulic system | 13.2 gal 50.0 L |
| Hydraulics | |
| Type | open center |
| Capacity | 13.2 gal 50.0 L |
| Pressure | 3046 psi 210.0 bar |
| Valves | 2 to 4 |
| Pump flow | 10.7 gpm 40.5 lpm |
| 17.9 gpmOptOptional 67.8 lpm | |
| Tractor hitch | |
| Rear Type | II |
| Control | position and draft control |
| Rear lift (at ends) | 5260 lbs 2385 kg |
| 6362 lbsOptOptional 2885 kg | |
| Power Take-off (PTO) | |
| Rear PTO | independent |
| Clutch | hydraulic wet disc |
| Rear PTO Type | 540/1000 (1.375) |
| Engine RPM | 540@1902 |
| 1000@2000 | |
| Dimensions & Tires | |
| Wheelbase | 103 inches 261 cm |
| Weight | 7624 to 9080 pounds |
| Front tire | 9.5L-15 |
| Rear tire | 18.4-30 |
 Full dimensions and tires ... | |
| 4263 Serial Numbers | |
| 1997 | F01001 |
| 1998 | G01001 |
| 1999 | H01001 |
FAQ: How to read a serial number table. | |
| Electrical | |
| Ground | negative |
| Charging system | alternator |
| ROPS Charging amps | 45 |
| Cab Charging amps | 70 |
| Batteries | 2 |
| Battery CCA | 590 |
| Battery volts | 12 |
| References | |
 | |
| MF Loaders for Compact & Agricultural Tractors published in 2003, by Massey Ferguson | |
| MF 4200 Series published in 1997, by Massey Ferguson | |
| MF 4200 Series published in 2000, by Massey Ferguson | |
| MF 4200 Series Tractors - MF 1000 Series Loaders Dealer Launch published in 1997, by Massey Ferguson | |
| MF 4200 Series Specifications published in 1997, by Massey Ferguson |
