Tractors > Massey Ferguson > 3545

Massey Ferguson 3545

Massey Ferguson 3545 tractor photo
1983 - 1987   3500 Series
Row-Crop tractor
Next model:Massey Ferguson 3650
Series back:Massey Ferguson 3525






Production:

Manufacturer:Massey Ferguson
Factory:France
Original price (USD):$47,500 (1987)


Massey Ferguson 3545 Engine:

   Perkins 5.8L 6-cyl diesel
full engine details ...


Capacity:



3-Point Hitch:

Rear Type:II
Rear lift (at 24"/610mm):7,611 lbs [3452 kg]


Power Take-off (PTO):

Rear PTO:independent
Rear RPM:540/1000


Dimensions & Tires:

Wheelbase:107 inches [271 cm]
Weight:13300 to 17235 pounds
Front tire:11.00-16
Rear tire:18.4-38
full dimensions and tires ...


3545 Serial Numbers:

Location:Instrument panel, right side
1983: K242206
1984: T101201
1985: L101201
1986: U031201
1987: V001201

how to read serial numbers...



Massey Ferguson 3545 Power:

Engine:147 hp [109.6 kW]
PTO (claimed):125 hp [93.2 kW]
Drawbar (tested):104.90 hp [78.2 kW]
PTO (tested):126.72 hp [94.5 kW]
power test details ...


Mechanical:

Chassis:4x2 2WD
 4x4 MFWD 4WD
Differential lock:hydraulic
Steering:hydrostatic power
Brakes:differential hydraulic wet disc
Cab:Cab with air-conditioning or four-post ROPS canopy.


Hydraulics:

Type:open center
Pressure:2539 psi [175.1 bar]
Valves:2 or 3
Pump flow:15 gpm [56.8 lpm]
Total flow:29.5 gpm [111.7 lpm] (total)
 14.5 gpm [54.9 lpm] (main pump)
 15 gpm [56.8 lpm] (two-spool aux pump)


Battery:

Volts:12
