Tractors > Massey Ferguson > 390

Massey Ferguson 390 - engine

Massey Ferguson 390 tractor photo
1987 - 1997   300 Series
Model years
Utility tractor
Previous model:Massey Ferguson 290
Series next:Massey Ferguson 398
Series back:Massey Ferguson 383
more Massey Ferguson 390 specifications...






Engine Detail:

 Perkins A4.248
 diesel
 4-cylinder
 liquid-cooled
 248 ci [4.1 L]
Bore/Stroke:3.975x5.00 inches [101 x 127 mm]
Power:81 hp [60.4 kW]
Air cleaner:dual dry element
Compression:15.5:1
Rated RPM:2200
Torque:210 lb-ft [284.8 Nm]
Torque RPM:1400
Firing order:1-3-4-2
Starter volts:12
Oil capacity:8 qts [7.6 L]
Coolant capacity:16 qts [15.1 L]
