Tractors > John Deere > 5090M

John Deere 5090M



John Deere 5090M tractor photo
2018 - 2022
5M Series
Utility tractor
Series map:
5085M
5090M
5100M
85.0hp
89.2hp
100.0hp
Production
ManufacturerJohn Deere
Utility tractor
Built in Augusta, Georgia, USA
Original price was $64,481 in 2021
John Deere 5090M Engine
John Deere 4.5L 4-cyl diesel
ROPS Fuel tank29.6 gal
112.0 L
ROPS Fuel tank37.3 galOptOptional
141.2 L
Cab Fuel tank36.7 gal
138.9 L
Cab Fuel tank45 galOptOptional
170.3 L
Engine details ...
John Deere 5090M Transmissions
12-speed partially synchronized
16-speed power shuttle
32-speed two-speed power shift
Transmission details ...
John Deere 5090M Power
Engine (gross)89.2 hp
66.5 kW
PTO (claimed)75 hp
55.9 kW
PTO (tested)83.74 hp
62.4 kW
Performance test details ...
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Differential lockelectro-hydraulic
Power steering
Hydraulic wet disc brakes
Isolated open operator station with foldable two-post ROPS. Optional premium open station features extended fenders and integral work lights. Standard and premium cabs available with air-conditioning.
Photos
No photos of the John Deere 5090M are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow18.4 gpm
69.6 lpm
Total flow24.7 gpm
93.5 lpm
Steering flow6.3 gpm
23.8 lpm
Tractor hitch
Rear TypeII/I
Controllower-link draft sensing
Rear lift (at 24"/610mm)5159 lbs
2340 kg
 5954 lbsOptOptional
2700 kg
Power Take-off (PTO)
Rear PTOindependent
Clutchelectro-hydraulic
Rear PTO Type540/540E
 540/540E/1000 OptOptional
Dimensions & Tires
Wheelbase92.5 inches
234 cm
Weight8140 to 9185 pounds
Front tire12.4R24
2WD Rear tire18.4R30
Full dimensions and tires ...
Electrical
Groundnegative
Charging systemalternator
Battery volts12
References
5090M references literature
5M Series published in 2018, by John Deere*
Operator's Manual 5094M, 5090M, 5100M, 5100MH, 5100ML, 5115M and 5115ML (FT4) Tractors (OMSU54598) published in 2017
*Publication contains known errors.
