Massey Ferguson 150 Engine


Massey Ferguson 150 tractor photo
1964 - 1975
50
Series:135150165
255
Engines overview
Perkins 2.5L 3-cyl diesel
Continental 2.4L 4-cyl gasoline
Perkins 2.5L 3-cyl gasoline
Engine Detail
Perkins AD3.152
diesel
3-cylinder
liquid-cooled
Displacement:152.7 ci
2.5 L
Bore/Stroke:3.6x5.0 inches
91 x 127 mm
Power:45.5 hp
33.9 kW
Air cleaner:oil bath
Compression:17.4:1
Rated RPM:2000
Torque:115 lb-ft
155.9 Nm
Torque RPM:1200
Starter volts:12
Oil capacity:6.3 qts
6.0 L
Coolant capacity:10.5 qts
9.9 L
Engine Detail
Continental Z-145
gasoline
4-cylinder
liquid-cooled
Displacement:145 ci
2.4 L
Bore/Stroke:3.375x4.062 inches
86 x 103 mm
Compression:7.1:1
Torque:125 lb-ft
169.5 Nm
Starter volts:12
Engine Detail
Perkins AG3.152
gasoline
3-cylinder
liquid-cooled
Displacement:152.7 ci
2.5 L
Bore/Stroke:3.6x5.0 inches
91 x 127 mm
Air cleaner:oil bath
Compression:7.5:1
Rated RPM:2000
Starter volts:12
Coolant capacity:10.5 qts
9.9 L
