New Holland 8360


New Holland 8360 tractor photo
1996 - 1999
60 Gemini Series
Row-Crop tractor
Series:826083608560
TM150
Production
Manufacturer:New Holland
Type:Row-Crop tractor
Factory:England
Original price:$56,000 (1999)
Variants
Fiat M135
New Holland 8360 Power
PTO (claimed):115 hp
85.8 kW
Drawbar (tested):100 hp
74.6 kW
PTO (tested):119 hp
88.7 kW
power test details ...
New Holland 8360 Engine
New Holland 7.5L 6-cyl diesel
Engine details ...
Mechanical
Chassis:4x2 2WD
 4x4 MFWD 4WD (optional)
Differential lock:Rear (2WD) or front and rear (4WD) with push-button operation. Manual and automatic modes.
Steering:hydrostatic power
Brakes:differential hydraulic wet disc
Cab:Two-post ROPS. Optional cab.
Transmissions:23-speed partially synchronized
 17-speed partial power shift
 18-speed partial power shift
Transmission details ...
Photos
No photos of the New Holland 8360 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel:85 gal
321.7 L
Hydraulic system:23.7 gal
89.7 L (18-speed)
 19.2 gal
72.7 L (23-speed)
Front hubs:2.3 qts
2.2 L (each)
Front diff.:3.7 qts
3.5 L
Hydraulics
Type:closed center load sensing
Capacity:23.7 gal
89.7 L (18-speed)
 19.2 gal
72.7 L (23-speed)
Pressure:2755 psi
190.0 bar
Valves:2 to 4
Pump flow:26 gpm
98.4 lpm
Steering flow:16.4 gpm
62.1 lpm
Steering press.:2465 psi
170.0 bar
Tractor hitch
Rear Type:II/III
Rear lift (at 24"/610mm):12,000 lbs
5443 kg
Power Take-off (PTO)
Rear PTO:independent
Rear RPM:540/1000
Dimensions & Tires
Wheelbase:108.3 inches
275 cm (2WD)
 107.2 inches
272 cm (4WD)
Weight:11836 to 13046 pounds
Front tire:11.00-16
Rear tire:18.4R38 (2WD)
Full dimensions and tires ...
Electrical
Ground:negative
Charging system:alternator
Charging amps:70
 100 (with cab)
Batteries:2
Battery CCA:900
Battery volts:12
