Nebraska Tractor Test 738: |
|
|
| Test Date: | April 5 - 23, 1960
|
| Type: | Gasoline 8-speed 2WD
|
| PTO power (rated engine speed): | 64.57 hp [48.1 kW]
|
| PTO fuel use (engine speed): | 5.1 gal/hour [19.3 l/hour]
|
| Drawbar power (max): | 53.34 hp [39.8 kW]
|
| Drawbar fuel use (max): | 4.8 gal/hour [18.2 l/hour]
|
| Drawbar pull (max): | 8,177 lbs [3709 kg]
|
| Max pull gear: | 2
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 740: |
|
|
| Test Date: | April 11 - 23, 1960
|
| Type: | LP gas 8-speed 2WD
|
| PTO power (rated engine speed): | 63.38 hp [47.3 kW]
|
| PTO fuel use (engine speed): | 6.5 gal/hour [24.6 l/hour]
|
| Drawbar power (max): | 52.99 hp [39.5 kW]
|
| Drawbar fuel use (max): | 6.2 gal/hour [23.5 l/hour]
|
| Drawbar pull (max): | 8,158 lbs [3700 kg]
|
| Max pull gear: | 4
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 777: |
|
|
| Test Date: | November 2 - 12, 1960
|
| Type: | Gasoline Case-O-Matic 2WD
|
| PTO power (max): | 63.78 hp [47.6 kW]
|
| PTO power (rated engine speed): | 65.64 hp [48.9 kW]
|
| PTO fuel use (engine speed): | 5.8 gal/hour [22.0 l/hour]
|
| PTO power (rated PTO speed): | 540 hp [402.7 kW]
|
| PTO fuel use (PTO speed): | 45.6 gal/hour [172.6 l/hour]
|
| Drawbar power (max): | 58.41 hp [43.6 kW]
|
| Drawbar fuel use (max): | 5.9 gal/hour [22.3 l/hour]
|
| Drawbar pull (max): | 8,474 lbs [3843 kg]
|
| Max pull gear: | 2
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 780: |
|
|
| Test Date: | November 4 - 19, 1960
|
| Type: | LP gas Case-O-Matic 2WD
|
| PTO power (max): | 62.60 hp [46.7 kW]
|
| PTO power (rated engine speed): | 65.96 hp [49.2 kW]
|
| PTO fuel use (engine speed): | 7.1 gal/hour [26.9 l/hour]
|
| PTO fuel use (PTO speed): | 9.74 hh/g [1.9 kWh/l]
|
| Drawbar power (max): | 57.46 hp [42.8 kW]
|
| Drawbar fuel use (max): | 7.1 gal/hour [26.9 l/hour]
|
| Drawbar pull (max): | 8,369 lbs [3796 kg]
|
| Max pull gear: | 3
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 919: |
|
|
| Test Date: | October 8 - 16, 1965
|
| Type: | Gasoline 8-speed 2WD CK
|
| PTO power (rated engine speed): | 65.24 hp [48.6 kW]
|
| PTO fuel use (engine speed): | 5.6 gal/hour [21.2 l/hour]
|
| PTO power (rated PTO speed): | 62.17 hp [46.4 kW]
|
| PTO fuel use (PTO speed): | 5.1 gal/hour [19.3 l/hour]
|
| Drawbar power (max): | 58.02 hp [43.3 kW]
|
| Drawbar fuel use (max): | 5.6 gal/hour [21.2 l/hour]
|
| Drawbar pull (max): | 8,126 lbs [3685 kg]
|
| Max pull gear: | 2
|
| Test report: | PDF file
|
| |
Nebraska Tractor Test 921: |
|
|
| Test Date: | October 9 - 25, 1965
|
| Type: | LP gas 8-speed 8-speed
|
| PTO power (rated engine speed): | 64.08 hp [47.8 kW]
|
| PTO fuel use (engine speed): | 7.5 gal/hour [28.4 l/hour]
|
| PTO power (rated PTO speed): | 61.26 hp [45.7 kW]
|
| PTO fuel use (PTO speed): | 6.6 gal/hour [25.0 l/hour]
|
| Drawbar power (max): | 58.24 hp [43.4 kW]
|
| Drawbar fuel use (max): | 7.5 gal/hour [28.4 l/hour]
|
| Drawbar pull (max): | 8,278 lbs [3754 kg]
|
| Max pull gear: | 2
|
| Test report: | PDF file
|
| |
