Tractors > J.I. Case > 801-B

J.I. Case 801-B - tests

J.I. Case 801-B tractor photo
1958 - 1960   800 B Series
Row-Crop tractor
Next model:J.I. Case 831
more J.I. Case 801-B specifications...






Nebraska Tractor Test 680:

801-B fuel use from test 680
Test Date:October 27 - November 14, 1958
Type:Diesel 8-speed 2WD
Belt power (max):54.42 hp [40.6 kW]
Belt fuel use (max):4.0 gal/hour [15.1 l/hour]
Drawbar power (max):51.38 hp [38.3 kW]
Drawbar fuel use (max):4.1 gal/hour [15.5 l/hour]
Drawbar pull (max):7,888 lbs [3577 kg]
Max pull gear:2
Test report:PDF file
