    International Harvester 6788

    No photo available
    1981 - 1984   60 2+2 Series
    Previous model:International Harvester 3788
    Smaller:International Harvester 6588






    Production:

    Manufacturer:International Harvester
    Total built:347
    Original price (USD):$70,500 (1984)


    International Harvester 6788 Engine:

       International Harvester 7.6L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:89 gal [336.9 L]
     139 gal [526.1 L] (optional)
    Hydraulic system:23.6 gal [89.3 L]


    3-Point Hitch:

    Rear Type:3, 2


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPM:1000


    Dimensions & Tires:

    Wheelbase:110 inches [279 cm]
    Weight:16,920 lbs [7674 kg]
    Front tire:18.4-38
    Rear tire:18.4-38
    full dimensions and tires ...


    6788 Serial Numbers:

    Location:transmission housing, right side
    1981: 8801
    1982: 8810
    1983: 8840
    1984: 8871
    1985: 8946

    how to read serial numbers...



    International Harvester 6788 Power:

    Engine:200 hp [149.1 kW]
    Drawbar (claimed):142 hp [105.9 kW]
    PTO (claimed):170 hp [126.8 kW]
    Drawbar (tested):142.05 hp [105.9 kW]
    PTO (tested):170.57 hp [127.2 kW]
    power test details ...


    Mechanical:

    Chassis:4x4 articulated 4WD
    Steering:articulated hydrostatic power
    Cab:Cab standard with burgundy finish, heat, and A/C. Optional wester finish interior.


    Hydraulics:

    Capacity:23.6 gal [89.3 L]
    Valves:2 to 4
    Pump flow:18 gpm [68.1 lpm]
    Steering flow:12 gpm [45.4 lpm]
