| | Production: |
| Manufacturer: | International Harvester
|
| Factory: | Doncaster, England
|
| Total built: | -unknown- |
| Original price: | $4,640 (1973)
|
| | |
| International Harvester 4-cyl gasoline |
| International Harvester 3-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 18.5 gal [70.0 L]
|
| | |
| Rear Type: | 1
|
| Rear lift: | 3,307 lbs [1500 kg]
|
| | |
| Rear PTO: | independent
|
| Rear RPMs: | 540/1000
|
| | |
| Wheelbase: | 75 inches [190 cm]
|
| Weight: | 3780 to 7470 pounds
|
| Front tire: | 6.00-16
|
| Rear tire: | 13.6-28
|
| full dimensions and tires ... | | | |
| Location: | Clutch housing, left side of tractor.
|
1970: 501
1971: 508
1972: 4908
1973: 8064
|
|
| | International Harvester 454 Power: |
| Engine: | 50 hp [37.3 kW]
|
| Drawbar (claimed): | 35 hp [26.1 kW]
|
| PTO (claimed): | 40 hp [29.8 kW]
|
| Drawbar (tested): | 35.35 hp [26.4 kW]
|
| PTO (tested): | 40.86 hp [30.5 kW]
|
| power test details ... | | | Mechanical: |
| Chassis: | 4x2 2WD
|
| Steering: | hydrostatic power
|
| Brakes: | independent hydraulic wet disc
|
|
|
| | Hydraulics: |
| Type: | -unknown- |
| Capacity: | -unknown- |
| Pressure: | -unknown- |
| Valves: | -unknown- |
| Total flow: | -unknown- |
| Valve flow: | 11.9 gpm [45.0 lpm]
|
| Steering flow: | -unknown- |
| | Electrical: |
| Ground: | -unknown- |
| Alternator amps: | 32
|
| | Battery: |
| Number: | 1 (gas)
2 (diesel)
|
| Cold-cranking amps: | -unknown- |
| Volts: | 12 (gas)
6 (diesel)
|
| Amp-hours: | 40 (gas)
135 (diesel)
|
