    Ford TW-30

    Ford TW-30 tractor photo  FO-201 I&T Manual: Ford Dextra, Major, Commander, 5000, 6000, 8000, 9000, TW
    I&T Shop Manual
    1979 - 1983   TW Series
    Row-Crop tractor
    Smaller:Ford TW-20






    Production:

    Manufacturer:Ford
    Original price (USD):$52,277


    Ford TW-30 Engine:

       Ford 6.6L 6-cyl diesel
    full engine details ...


    Capacity:

    Fuel:75 gal [283.9 L]
     24 gal [90.8 L] (auxiliary tank)


    3-Point Hitch:

    Rear Type:III
    Rear lift (at 24"/610mm):6,825 lbs [3095 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:1000


    Dimensions & Tires:

    Wheelbase:110.5 inches [280 cm]
    Weight:14600 to 19830 pounds
    Front tire:11.00-16
    Rear tire:18.4-38
    full dimensions and tires ...


    TW-30 Serial Numbers:

    Location:Under right grill panel
    1979: C592200
    1980: C635700
    1981: C660700
    1982: C682200
    1983: C694500

    how to read serial numbers...



    Ford TW-30 Power:

    Engine (gross):188.2 hp [140.3 kW]
    Engine:175 hp [130.5 kW]
    Drawbar (claimed):144.2 hp [107.5 kW]
    PTO (claimed):163 hp [121.5 kW]
    Drawbar (tested):142.21 hp [106.0 kW]
    PTO (tested):163.28 hp [121.8 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
     4x4 MFWD 4WD (optional)
    Steering:hydrostatic power
    Brakes:differential power assist wet disc
    Cab:Cab optional.


    Hydraulics:

    Type:23
    Pressure:2500 psi [172.4 bar]
    Pump flow:20 gpm [75.7 lpm]
     8 gpm [30.3 lpm] (service pump)
    Steering flow:4.2 gpm [15.9 lpm]


    Electrical:

    Charging system:alternator
    Charging amps:72


    Battery:

    Number:1
    Volts:12
    Amp-hours:128
