    John Deere 1650




    No photo available  I&T Manual: Deere 1250, 1450, 1650
    I&T Shop Manual
    Model:1650
    Years:1984 - 1988
    Tractor type:Farm/Agricultural tractor
    Original price:$19,000 (1988)


    Production:

    Factory:Japan
    Distributor:John Deere
    Manufacturer:Yanmar
    Total built:-unknown-


    Engine:

       Yanmar 4-cyl diesel
    full engine details ...


    Capacity:

    Fuel:21.2 gal [80.2 L]


    3-Point Hitch:

    Rear Type:II
    Rear lift:2,690 lbs [1220 kg]


    Power Take-off (PTO):

    Rear PTO:independent
    Rear RPMs:540


    Dimensions & Tires:

    Wheelbase:82.8 inches [210 cm]
    Weight:4,650 lbs [2109 kg]
    Front tire:6.50-16
    Rear tire:16.9-28
    full dimensions and tires ...


    Serial Numbers:

    Location:Below PTO on rear of tractor
    1984: 1021
    1985: 2401
    1986: 3001
    1987: 3501
    1988: 3579


    Power:

    Engine:67 hp [50.0 kW]
    Drawbar (claimed):54 hp [40.3 kW]
    PTO (claimed):62 hp [46.2 kW]
    Drawbar (tested):54.1 hp [40.3 kW]
    PTO (tested):62.2 hp [46.4 kW]
    power test details ...


    Mechanical:

    Chassis:4x2 2WD
    4x4 MFWD 4WD (optional)
    Steering:-unknown-
    Brakes:-unknown-


    Hydraulics:

    Type:open
    Capacity:33.3 gal [126.0 L]
    Total flow:-unknown-
    Valve flow:10.2 gpm [38.6 lpm]
    Steering flow:-unknown-
    Pressure:-unknown-
    Valves:2


    Electrical:

    Ground:-unknown-
