| | Production: |
| Factory: | Waterloo, Iowa, USA
|
| Manufacturer: | John Deere
|
| Series: | Iron Horses
|
| Total built: | -unknown- |
| | |
| John Deere 6-cyl diesel |
| full engine details ... | | | Capacity: |
| Fuel: | 65 gal [246.0 L]
|
| | |
| Rear Type: | II, III
|
| Rear lift: | 5,710 lbs [2590 kg]
|
| | |
| Rear PTO: | independent
|
| Rear RPMs: | 540, 1000
|
| | |
| Wheelbase: | 107 inches [271 cm]
|
| Weight: | 12,000 lbs [5443 kg]
|
| Front tire: | 10.00-16
|
| Rear tire: | 18.4-38
|
| full dimensions and tires ... | | | |
| Location: | Back of transmission case
|
1978: 1000
1979: 14820
1980: 29539
1981: 42665
1982: 56346
|
|
| | Power: |
| Engine: | -unknown- |
| Drawbar (claimed): | 112 hp [83.5 kW]
|
| PTO (claimed): | 130 hp [96.9 kW]
|
| Drawbar (tested): | 112.6 hp [84.0 kW]
|
| PTO (tested): | 130.6 hp [97.4 kW]
|
| power test details ... | | | Mechanical: |
| Chassis: | 4x2 2WD
4x4 MFWD 4WD (optional)
|
| Steering: | -unknown- |
| Brakes: | -unknown- |
| Cab: | standard
|
|
|
| | Hydraulics: |
| Type: | closed
|
| Capacity: | 11 gal [41.6 L]
|
| Total flow: | -unknown- |
| Valve flow: | 23 gpm [87.1 lpm]
|
| Steering flow: | -unknown- |
| Pressure: | -unknown- |
| Valves: | 2
|
| | Electrical: |
| Ground: | -unknown- |
