John Deere 4040 Tests
|
|
| Tractor Tests | |
| NTTL 1267: diesel Quad-Range 2WD | |
| NTTL 1359: diesel Syncro-Range 2WD | |
| NTTL 1360: diesel Powershift 2WD |
| Nebraska Tractor Test 1267 | |||
| |||
| Nebraska Tractor Test 1267 | |
| Diesel Quad-Range 2WD November 12 - 28, 1977 Link: Nebraska Tractor Test 1267 file | |
| PTO performance | |
| Power at rated engine speed | 90.80 hp 67.7 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Drawbar performance | |
| Max power | 74.83 hp 55.8 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Max pull | 8,936 lbs 4053 kg |
| Nebraska Tractor Test 1359 | |||
| |||
| Nebraska Tractor Test 1359 | |
| Diesel Syncro-Range 2WD August 20 - September 9, 1980 Link: Nebraska Tractor Test 1359 file | |
| PTO performance | |
| Power at rated engine speed | 90.31 hp 67.3 kW |
| Fuel use | 6.5 gal/hour 24.6 l/hour |
| Drawbar performance | |
| Max power | 73.83 hp 55.1 kW |
| Fuel use | 6.3 gal/hour 23.8 l/hour |
| Gear 4 used for power test. | |
| Max pull | 9,035 lbs 4098 kg |
| Gear 2 used for pull test. | |
| Nebraska Tractor Test 1360 | |||
| |||
| Nebraska Tractor Test 1360 | |
| Diesel Powershift 2WD August 20 - September 11, 1980 Link: Nebraska Tractor Test 1360 file | |
| PTO performance | |
| Power at rated engine speed | 90.79 hp 67.7 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Power at rated PTO speed | 90.88 hp 67.8 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Drawbar performance | |
| Max power | 76.56 hp 57.1 kW |
| Fuel use | 6.7 gal/hour 25.4 l/hour |
| Gear 4 used for power test. | |
| Max pull | 9,195 lbs 4170 kg |
| Gear 2 used for pull test. | |
