    John Deere 4230 - tests

    John Deere 4230 tractor photo  I&T Manual: Deere 4630, 4030, 4230, 4430
    I&T Shop Manual
    Production years:1973 - 1977
    Previous model:John Deere 4020
    Tractor type:Farm/Agricultural tractor
    Larger:John Deere 4430
    Smaller:John Deere 4030
    more John Deere 4230 specifications...






    Nebraska Tractor Test 1112:

    Test Date:October 13 - 24, 1972
    Type:Quad-Range 2WD
    Engine:diesel
    PTO power (rated engine speed):100.32 hp [74.8 kW]
    PTO fuel use (engine speed):7.1 gal/hour [26.9 l/hour]
    Drawbar power (max):83.95 hp [62.6 kW]
    Drawbar fuel use (max):7.0 gal/hour [26.5 l/hour]
    Drawbar pull (max):11,150 lbs [5057 kg]
    Max pull gear:A2
    Test report:PDF file
