J.I. Case 780C


J.I. Case 780C backhoe photo
1981 - 1988
Backhoe loader tractor
780B
Series:780C
780D
Production
ManufacturerJ.I. Case
TypeBackhoe loader tractor
J.I. Case 780C Power
Engine (gross)124 hp
92.5 kW
Engine (net)112 hp
83.5 kW
Mechanical
Chassis4x2 2WD
Final drivesoutboard planetary
Steeringpower
CabFour-post ROPS/FOPS canopy. Optional cab with available air-conditioning.
Photos
No photos of the J.I. Case 780C are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Capacity
Fuel43 gal
162.8 L
Hydraulic system18.9 gal
71.5 L
Hydraulics
Typeopen center
Capacity18.9 gal
71.5 L
Pressure2000 psi
137.9 bar
Pump flow31.5 gpm (loader)
119.2 lpm
 59.3 gpm (backhoe)
224.5 lpm
Steering flow27.8 gpm
105.2 lpm
Steering press.2000 psi
137.9 bar
Dimensions & Tires
Wheelbase87 inches
220 cm
Weight18212 to 20421 pounds
Front tire14x17.5
Rear tire18.4x24
Full dimensions and tires ...
Backhoe & Loader
Dig depth219 inches
556 cm
Dump angle49 inches
124 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Charging systemalternator
Charging amps65
Batteries2
Battery volts12
References
780C reference literature
Model 780C Loader/Backhoe published by J.I. Case
