Tractors > Cub Cadet > Sc2450 backhoe-loader

Cub Cadet Sc2450



Cub Cadet Sc2450 backhoe photo
2009 - 2011
Backhoe loader tractor
Yanmar built
Production
DistributorCub Cadet
ManufacturerYanmar
TypeBackhoe loader tractor
Variants
Sc2400compact tractor
Sc2450compact backhoe
Cub Cadet Sc2450 Engine
Yanmar 0.9L 3-cyl diesel
Fuel tank5.8 gal
22.0 L
Engine details ...
Cub Cadet Sc2450 Transmission
hydrostatic
Transmission details ...
Cub Cadet Sc2450 Power
Engine (gross)24 hp
17.9 kW
PTO (claimed)16.5 hp
12.3 kW
Mechanical
Chassis4x4 MFWD 4WD
Steeringhydraulic power
Brakeswet disc
Photos
No photos of the Cub Cadet Sc2450 are currently available. To submit yours, email it to Peter@TractorData.com. Photos may only be used with the permission of the original photographer.
Hydraulics
Typeopen center
Pump flow3.5 gpm
13.2 lpm
 3.4 gpm (trans/PTO)
12.9 lpm
Total flow6.9 gpm
26.1 lpm
Tractor hitch
Rear Type1 (limited)
Controlposition control
Rear lift (at 24"/610mm)661 lbs
299 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540
Engine RPM540@31111
Mid PTOindependent
Mid RPM2100
Engine RPM2100@3338
Dimensions & Tires
Wheelbase55.1 inches
139 cm
Weight2,525 lbs
1145 kg
Front tire18x8.5-10
Rear tire26x12.0-12
Full dimensions and tires ...
Backhoe & Loader
Dig depth76.5 inches
194 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Battery volts12
