Kubota B26

Kubota B26 backhoe photo
2007 - ????
Backhoe loader tractor
TypeBackhoe loader tractor
Original price$33,673 (2011)
Kubota B26 Engine
Kubota 1.1L 3-cyl diesel
Engine details ...
Kubota B26 Power
Engine (gross)26 hp
19.4 kW
Engine (net)23.3 hp
17.4 kW
PTO (claimed)19.5 hp
14.5 kW
Chassis4x4 MFWD 4WD
Differential lockrear standard
Steeringhydrostatic power
Brakeswet disc
CabFour-post ROPS with FOPS canopy standard.
Fuel8.2 gal
31.0 L
Front axle4.7 qts
4.4 L
Typeopen center
Valves1 to 3
Pump flow7 gpm
26.5 lpm
Total flow11.2 gpm
42.4 lpm
Tractor hitch
Rear TypeI
Rear lift (at 24"/610mm)1,676 lbs
760 kg
Power Take-off (PTO)
Rear PTOindependent
Rear RPM540 (1.375)
Engine RPM540@2768
Dimensions & Tires
Wheelbase62.2 inches
157 cm
Weight4,001 lbs
1814 kg
Front tire23x8.50-14
Rear tire12.4-16
Full dimensions and tires ...
Backhoe & Loader
Dig depth99.8 inches
253 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Charging systemalternator
Charging amps40
Battery volts12
Battery AH36
