John Deere 310D


John Deere 310D backhoe photo
1991 - 1997
Backhoe loader tractor
Series map:
310D
70.0hp
Production
ManufacturerJohn Deere
Backhoe loader tractor
John Deere 310D Engine
John Deere 3.9L 4-cyl diesel
Engine details ...
John Deere 310D Power
Engine75 hp
55.9 kW
Mechanical
Two- or four-wheel drive
Final drivesinboard planetary
Power steering
Differential hydraulic wet disc brakes
Four-post ROPS canopy. Cab optional with air-conditioning.
Capacity
Fuel34 gal
128.7 L
Hydraulic system21 gal
79.5 L
Hydraulics
Typeopen center
Capacity21 gal
79.5 L
Pressure2700 psi
186.2 bar
Total flow38 gpm
143.8 lpm
Steering flow6.4 gpm
24.2 lpm
Steering press.2850 psi
196.5 bar
Dimensions & Tires
Wheelbase83 inches
210 cm
Weight13600 to 14290 pounds
Full dimensions and tires ...
Backhoe & Loader
Dig depth174 inches
441 cm
Dump angle45 inches
114 cm
Loader/Backhoe details ...
Electrical
Groundnegative
Charging systemDelco alternator
 Bosch alternator (after SN787514)
Charging amps78
 92 (after SN787514)
Battery volts12
References
310D references literature
Utility/Construction Purchasing Guide published in 1995, by John Deere
