| | 1990 - 1992 |
| 1600 Series | | Lawn tractor | | Simplicity built |
|
Series map:
1613H
1616H
12.5hp
16.0hp
| Engine Detail |
| Briggs & Stratton |
| gasoline |
| 2-cylinder |
| air-cooled vertical-shaft |
| Displacement | 480 cc
29.3 ci
|
| Bore/Stroke | 2.68x2.60 inches
68 x 66 mm
|
| Power (gross) | 16 hp
11.9 kW
|
| Starter | electric
|
| Starter volts | 12
|
| Oil capacity | 1.75 qts
1.7 L
|
| Deutz-Allis 1616H Engine |
 |
