Craftsman 917.25151 Engine


Craftsman 917.25151 lawn tractor photo
1996
Garden tractor
AYP built
Engine Detail
Kohler CV20S
gasoline
2-cylinder
air-cooled vertical-shaft V-Twin
Displacement624 cc
38.1 ci
Bore/Stroke3.03x2.64 inches
77 x 67 mm
Power20.5 hp
15.3 kW
Starterelectric
Starter volts12
SparkplugChampion RC12YC
Sparkplug gap0.030 inches
0.762 mm
Engine Oil
917.25151 gasoline engine oil chart
Oil capacity4.2 qts
4.0 L
