Toro GMT 200 30802 Engine

Toro GMT 200 30802 lawn tractor photo
1978 - 1983
Series map:
GMT 200
GMT 230
Engine Detail
Kohler K532S
air-cooled horizontal-shaft
Displacement880 cc
53.7 ci
Bore/Stroke3.375x3.00 inches
86 x 76 mm
Power20 hp
14.9 kW
Rated RPM3450
Torque38.3 lb-ft
51.9 Nm
Torque RPM2200
Starter volts12
Oil capacity3 qts
2.8 L
SparkplugChampion RH-10
Sparkplug gap0.025 inches
0.635 mm
