Cub Cadet AGS 2160 Transmission


Cub Cadet AGS 2160 lawn tractor photo
1994 - 1997
2000 Series
Garden tractor
Series map:
2155
2160
2165
15.0hp
16.0hp
16.0hp
Transmission
TransmissionAuto Gear System
Typeshaft-driven gear
Gears6 forward and reverse
Oil capacity6 qts
5.7 L
The Cub Cadet Auto Gear uses a six-speed transmission with forward and reverse foot pedals. The pedals control a clutch and should be fully depressed for whichever gear is selected. Using the pedals as a speed control will result in premature clutch failure.
