| | 2006 - 2015 |
|
| Select X300 Series | | Lawn tractor |
|
Series map:
X304
X324
17.0hp
22.0hp
| Transmission |
| Transmission | Tuff Torq K58
|
| Type | belt-driven hydrostatic
|
| Gears | infinite forward and reverse
|
| Oil change | sealed unit, owner service is not recommended
|
| The K58 was used on the X304 from the beginning of production through the 2007 model year. |
| Speeds |
|
| X304 Transmission Controls |
 |
| 1 | Throttle
|
| 2 | Brake
|
| 3 | Forward
|
| 4 | Reverse
|
| 5 | Cruise control
|
| 6 | Parking brake
|
| Transmission |
| Transmission | Tuff Torq K46CC
|
| Type | belt-driven hydrostatic
|
| Gears | infinite forward and reverse
|
| The K46 was used on the X304 starting with the 2008 model year, tractor serial number 085000. |
| Speeds |
|
