J.I. Case 310G Loader Engine
|
|
| Engines overview | |
| J.I. Case 3.1L 4-cyl diesel | |
| J.I. Case 2.4L 4-cyl gasoline |
| Engine Detail | |
| J.I. Case G188D | |
| diesel | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 188 ci 3.1 L |
| Bore/Stroke | 3.813x4.125 inches 97 x 105 mm |
| Power | 42.4 hp 31.6 kW |
| Air cleaner | oil bath |
| Compression | 17.5:1 |
| Rated RPM | 1850 |
| Torque | 128 lb-ft 173.6 Nm |
| Torque RPM | 1200 |
| Starter | electric |
| Starter volts | 12 |
| J.I. Case 310G Loader Engine | |
 |
| Engine Detail | |
| J.I. Case G148B | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| Displacement | 148 ci 2.4 L |
| Bore/Stroke | 3.375x4.125 inches 86 x 105 mm |
| Power | 42.4 hp 31.6 kW |
| Air cleaner | oil bath |
| Compression | 7.1:1 |
| Rated RPM | 1850 |
| Torque | 128 lb-ft 173.6 Nm |
| Torque RPM | 1300 |
| Starter | electric |
| Starter volts | 12 |
| J.I. Case 310G Loader Engine | |
 |
