Kubota M115D Transmission


No photo available
2005 - 2008
Grandom Series
Utility tractor
M115
Series:M105DM115DM125D
M115A
Transmissions overview
16-speed power shift
24-speed creeper
Transmission
Type:power shift
Gears:16 forward and reverse
Clutch:hydraulic wet disc
Eight power-shift gears in two ranges with shuttle.
Speeds
M115D  power shift speeds
Transmission
Type:creeper
Gears:24 forward and reverse
Optional creeper adds an additional 8-speed range to the standard transmission.
Speeds
M115D  creeper speeds
