Kubota M125 Transmission


Kubota M125 tractor photo
2002 - 2004
Grandom Series
Utility tractor
Series:M115M125
M125D
Transmissions overview
16-speed synchromesh
16-speed power shift
24-speed creeper
Transmission
Type:synchromesh
Gears:16 forward and reverse
Clutch:dry disc
Four gears (1-4) in two ranges with additional high/low shift.
Speeds
M125  synchromesh speeds
Transmission
Type:power shift
Gears:16 forward and reverse
Clutch:hydraulic wet disc
Eight power-shift gears in two ranges with shuttle.
Speeds
M125  power shift speeds
Transmission
Type:creeper
Gears:24 forward and reverse
1C:2C:3C:4C:5C:6C:7C:8C;:0.15:0.19:0.23:0.27:0.35:0.45:0.56:0.67
