Kubota KL430 Transmission


No photo available
2006 - 2007
KL Series
Compact Utility tractor
KL43
Series:KL360KL430
KL415
Transmissions overview
16-speed
24-speed
Transmission
Gears:16 forward and reverse
Four gears (1-4) in two ranges with additional creeper range and shuttle shift.
Speeds
KL430   speeds
Transmission
Gears:24 forward and 16 reverse
Twelve gears in two ranges (creeper and high) with shuttle shift. Only eight gears available in reverse.
