CaseIH JX55 Maxxima Transmission


CaseIH JX55 Maxxima tractor photo
2002 - 2006
Model year
JX Series
Utility tractor
Turk Tractor built
Series map:
JX55
JX65
55.0hp
62.0hp
Transmissions overview
12-speed mechanical shuttle
20-speed creeper
Transmission
Typemechanical shuttle
Gears12 forward and reverse
Clutchdry disc
Four gears (1-4) in three ranges with mechanical shuttle.
Speeds
JX55 Maxxima  mechanical shuttle speeds
Shift Pattern
CaseIH JX55 transmission controls
Transmission
Typecreeper
Gears20 forward and 12 reverse
