Tractors > John Deere > 1025R

John Deere 1025R Attachments



John Deere 1025R tractor photo
2013 -
1 Sub-Compact Series
Sub-Compact Utility tractor
Series map:
1025R
23.8hp
Attachment overview
54" mid-mount mower deck
60" mid-mount mower deck
Snowblower
Blade
John Deere D120 loader
John Deere H120 loader
Backhoe
54" Mower deck
John Deere 54D
54 inches
137 cm
3-blade
right-discharge
60" Mower deck
John Deere 60D 7-Iron
60 inches
152 cm
3-blade
right-discharge
54" Blade
John Deere
front-mount
54 inches width
137 cm
54" Snow blower
John Deere
54 inches width
137 cm
two-stage
front-mount
hydraulic-lift
D120 Loader
825 lbs lift (full at pin)
374 kg
570 lbs lift (full at 500mm)
258 kg
944 lbs lift (1.5m at pin)
428 kg
680 lbs lift (1.5m at 500mm)
308 kg
1808 lbs breakout (at pin)
820 kg
1238 lbs breakout (at 500mm)
561 kg
40.1° dump
22.5 inches reach (dumped)
57 cm
31.2° rollback
71.2 inches height (at pin)
180 cm
weight: 488 lbs
221 kg
Bucket width: 49 inches
124 cm
Bucket width: 53 inches
134 cm
Bucket width: 61 inches
154 cm
H120 Loader
836 lbs lift (full at pin)
379 kg
576 lbs lift (full at 500mm)
261 kg
955 lbs lift (1.5m at pin)
433 kg
686 lbs lift (1.5m at 500mm)
311 kg
1819 lbs breakout (at pin)
825 kg
1245 lbs breakout (at 500mm)
564 kg
40.1° dump
22.5 inches reach (dumped)
57 cm
31.2° rollback
71.2 inches height (at pin)
180 cm
weight: 541 lbs
245 kg
Bucket width: 49 inches
124 cm
Bucket width: 53 inches
134 cm
Bucket width: 61 inches
154 cm
John Deere 260 Backhoe
Backhoe typeJohn Deere 260 Backhoe
Weight610 lbs
276 kg
Digging depth74 inches
187 cm
Reach from pivot104 inches
264 cm
Swing Arc150°
Bucket force2036 lbs
923 kg
Dipperstick force1187 lbs
538 kg
