Tractors > New Holland > T9.615

New Holland T9.615 Tests



New Holland T9.615 tractor photo
2011 - 2014
T9 Series
Four-wheel Drive (4WD) tractor
Series map:
T9.560
T9.615
T9.670
507.0hp
542.0hp
608.0hp
OCED Tractor Test 2016
T9.615 fuel use from test 798
OCED Tractor Test 2016
Diesel 16-speed 4WD
November 29 - December 1, 2011
Link: OCED Tractor Test 2016 file
PTO performance
Max power530.46 hp
395.6 kW
Fuel use27.6 gal/hour
104.5 l/hour
Power at rated engine speed473.41 hp
353.0 kW
Fuel use26.3 gal/hour
99.5 l/hour
Power at rated PTO speed514.77 hp
383.9 kW
Fuel use27.5 gal/hour
104.1 l/hour
Drawbar performance
Max power426.74 hp
318.2 kW
Fuel use26.3 gal/hour
99.5 l/hour
Gear 5 used for power test.
Max pull46586 lbs
21131 kg
Gear 2 used for pull test.
