Ford 5640 Tests


Ford 5640 tractor photo
1991 - 1995
PowerStar 40 Series
Utility tractor
Series map:
5640
6640
78.7hp
90.7hp
OCED Tractor Test 1656
5640 fuel use from test 105
OCED Tractor Test 1656
Diesel 16x4 4WD
April 22 - May 12, 1992
Link: OCED Tractor Test 1656 file
PTO performance
Power at rated engine speed66.26 hp
49.4 kW
Fuel use4.1 gal/hour
15.5 l/hour
Power at rated PTO speed63.17 hp
47.1 kW
Fuel use3.8 gal/hour
14.4 l/hour
Drawbar performance
Max power59.99 hp
44.7 kW
Fuel use4.2 gal/hour
15.9 l/hour
Gear 5-Low used for power test.
Max pull8,611 lbs
3905 kg
Gear 2H used for pull test.
