Ford 3930 Tests
|
|
| Tractor Tests | |
| OECD 1644: 3.3L diesel 8x2 speed 4WD | |
| OECD 1341: diesel 8x8 speed | |
| OECD 1701: 3.1L diesel 8x2 speed 4WD | |
| OECD 1702: 3.1L diesel 8x8 speed 4WD | |
| OECD 1702S: 3.1L turbo-diesel 8x8 speed 4WD |
| OCED Tractor Test 1644 | |||
| |||
| OCED Tractor Test 1644 | |
| 3.3L diesel 8x2 speed 4WD April 8 - 25, 1991 Link: OCED Tractor Test 1644 file | |
| PTO performance | |
| Power at rated engine speed | 45.85 hp 34.2 kW |
| Fuel use | 2.8 gal/hour 10.6 l/hour |
| Power at rated PTO speed | 43.65 hp 32.5 kW |
| Fuel use | 2.6 gal/hour 9.8 l/hour |
| Drawbar performance | |
| Max power | 38.18 hp 28.5 kW |
| Fuel use | 2.9 gal/hour 11.0 l/hour |
| Gear 1H used for power test. | |
| Max pull | 4,807 lbs 2180 kg |
| Gear 2L used for pull test. | |
| OCED Tractor Test 1341 | |
| Diesel 8x8 speed | |
| PTO performance | |
| Max power | 44.3 hp 33.0 kW |
| Fuel use | 2.9 gal/hour 11.0 l/hour |
| Drawbar performance | |
| Max power | 35.1 hp 26.2 kW |
| OCED Tractor Test 1701 | |||
| |||
| OCED Tractor Test 1701 | |
| 3.1L diesel 8x2 speed 4WD October 17 - 27, 1995 Link: OCED Tractor Test 1701 file | |
| PTO performance | |
| Power at rated engine speed | 45.58 hp 34.0 kW |
| Fuel use | 3.0 gal/hour 11.4 l/hour |
| Power at rated PTO speed | 41.22 hp 30.7 kW |
| Fuel use | 2.6 gal/hour 9.8 l/hour |
| Drawbar performance | |
| Max power | 37.33 hp 27.8 kW |
| Gear 1H used for power test. | |
| Max pull | 5,026 lbs 2279 kg |
| Gear 2L used for pull test. | |
| OCED Tractor Test 1702 | |||
| |||
| OCED Tractor Test 1702 | |
| 3.1L diesel 8x8 speed 4WD October 2 - 27, 1995 Link: OCED Tractor Test 1702 file | |
| PTO performance | |
| Power at rated engine speed | 46.23 hp 34.5 kW |
| Fuel use | 3.2 gal/hour 12.1 l/hour |
| Power at rated PTO speed | 41.81 hp 31.2 kW |
| Fuel use | 2.7 gal/hour 10.2 l/hour |
| Drawbar performance | |
| Max power | 37.19 hp 27.7 kW |
| Fuel use | 3.1 gal/hour 11.7 l/hour |
| Gear 1H used for power test. | |
| Max pull | 4,480 lbs 2032 kg |
| Gear 3L used for pull test. | |
| OCED Tractor Test 1702S | |
| 3.1L turbo-diesel 8x8 speed 4WD 1998 | |
| PTO performance | |
| Power at rated engine speed | 52.54 hp 39.2 kW |
