Ferguson TEA-20 Engine
|
|
Series map:
TEA-20
31.1hp*
*Estimated engine power for comparison only.
| Engine options | |
| Standard 1.9L 4-cyl gasoline | |
| Standard 2.1L 4-cyl gasoline |
| Engine Detail | |
| Standard | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| The original, 80mm bore, engine was used until tractor serial number 172598 (engine number 100204) in 1951. | |
| Displacement | 112.9 ci 1.9 L |
| Bore/Stroke | 3.19x3.75 inches 81 x 95 mm |
| Air cleaner | oil bath |
| Rated RPM | 2000 |
| Idle RPM | 400-2000 |
| Firing order | 1-3-4-2 |
| Starter volts | 6 |
| Intake valve clearance | 0.010 inches (cold) 0.254 mm |
| Exhaust valve clearance | 0.012 inches (cold) 0.305 mm |
| Engine Oil | |
| |
| Oil capacity | 6 qts 5.7 L |
| Oil change | 120 h |
| Engine Detail | |
| Standard | |
| gasoline | |
| 4-cylinder | |
| liquid-cooled | |
| The 85mm bore engine was used in the TEA-20 beginning in 1951. The larger engine provided an increase to 28 horsepower. | |
| Displacement | 127.4 ci 2.1 L |
| Bore/Stroke | 3.375x3.65 inches 86 x 93 mm |
| Firing order | 1-3-4-2 |
| Starter volts | 6 |
| 12 (late) | |
