Challenger MT565B Tests
|
|
| Tractor Tests | |
| OECD 2308: diesel Autopower IV 4WD | |
| OECD 2335: diesel CVT 4WD |
| OCED Tractor Test 2308 | |||
| |||
| OCED Tractor Test 2308 | |
| Diesel Autopower IV 4WD September 2005 - October 2005, Link: OCED Tractor Test 2308 file | |
| PTO performance | |
| Max power | 151.8 hp 113.2 kW |
| Fuel use | 9.0 gal/hour 34.1 l/hour |
| Power at rated engine speed | 146.1 hp 108.9 kW |
| Fuel use | 9.2 gal/hour 34.8 l/hour |
| Power at rated PTO speed | 151.1 hp 112.7 kW |
| Fuel use | 9.0 gal/hour 34.1 l/hour |
| Drawbar performance | |
| Max power | 125.0 hp 93.2 kW |
| Gear 1LA used for power test. | |
| Max pull | 12,995 lbs 5894 kg |
| Gear 1TD used for pull test. | |
| OCED Tractor Test 2335 | |||
| |||
| OCED Tractor Test 2335 | |
| Diesel CVT 4WD April 2005 - June 2005, Link: OCED Tractor Test 2335 file | |
| PTO performance | |
| Max power | 153.1 hp 114.2 kW |
| Fuel use | 9.6 gal/hour 36.3 l/hour |
| Power at rated engine speed | 145.6 hp 108.6 kW |
| Fuel use | 9.7 gal/hour 36.7 l/hour |
| Power at rated PTO speed | 152.2 hp 113.5 kW |
| Fuel use | 9.7 gal/hour 36.7 l/hour |
| Drawbar performance | |
| Max power | 120.6 hp 89.9 kW |
