Tractors > McCormick-Deering > WD-6

McCormick-Deering WD-6 Tests



McCormick-Deering WD-6 tractor photo
1940 - 1952
Standard-tread tractor
Series map:
WD-6
40.4hp*
*Estimated engine power for comparison only.
Nebraska Tractor Test 356
WD-6 fuel use from test 356
Nebraska Tractor Test 356
Diesel 5-speed 2WD
September 20 - 27, 1940
Link: Nebraska Tractor Test 356 file
Belt power (max)34.75 hp
25.9 kW
Belt fuel use (max)2.3 gal/hour
8.7 l/hour
Drawbar performance
Max power31.02 hp
23.1 kW
Gear 3 used for power test.
Max pull4806 lbs
2180 kg
Gear 1 used for pull test.
