New Holland TG255 Tests


New Holland TG255 tractor photo
2002 - 2006
TG Series
Row-Crop tractor
Series:TG230TG255TG285
TG275
OCED Tractor Test 1831
TG255 fuel use from test 419
OCED Tractor Test 1831
Diesel 18-speed 4WD
September 18 - October 27, 2003
Link: OCED Tractor Test 1831 file
PTO performance
Max power:246.00 hp
183.4 kW
Fuel use:13.5 gal/hour
51.1 l/hour
Power at rated engine speed:216.48 hp
161.4 kW
Fuel use:12.4 gal/hour
46.9 l/hour
Power at rated PTO speed:245.98 hp
183.4 kW
Fuel use:13.5 gal/hour
51.1 l/hour
Drawbar performance
Max power:179.63 hp
134.0 kW
Fuel use:12.4 gal/hour
46.9 l/hour
Gear 7 used for power test.
Max pull:20629 lbs
9357 kg
Gear 5 used for pull test.
