John Deere 9320 Tests


John Deere 9320 tractor photo
2002 - 2007
9020 Series
Four-wheel Drive (4WD) tractor
9300
Series:922093209420
9330
OCED Tractor Test 9320
9320 fuel use from test 369
OCED Tractor Test 9320
Diesel 18-speed 4WD
April 9 - May 31, 2002
Link: OCED Tractor Test 9320 file
PTO performance
Max power:377.55 hp
281.5 kW
Fuel use:20.9 gal/hour
79.1 l/hour
Power at rated engine speed:333.43 hp
248.6 kW
Fuel use:19.0 gal/hour
71.9 l/hour
Power at rated PTO speed:364.94 hp
272.1 kW
Fuel use:20.0 gal/hour
75.7 l/hour
Drawbar performance
Max power:304.37 hp
227.0 kW
Fuel use:19.0 gal/hour
71.9 l/hour
Gear 6 used for power test.
Max pull:38,397 lbs
17416 kg
Gear 1 used for pull test.
