Kubota L210 Engine


Kubota L210 tractor photo
1972 - 1973
Compact Utility tractor
Engine Detail
Kubota Z1100A
diesel
2-cylinder
liquid-cooled
Displacement65.3 ci
1.1 L
Bore/Stroke3.46x3.46 inches
88 x 88 mm
Power (gross)21 hp
15.7 kW
Air cleaneroil bath
Compression20:1
Rated RPM2700
Starter volts12
Coolant capacity7.9 qts
7.5 L
Intake valve clearance0.009 inches (cold)
0.229 mm
Exhaust valve clearance0.009 inches (cold)
0.229 mm
Engine Oil
L210 diesel engine oil chart
Oil capacity5.3 qts
5.0 L
