CaseIH 2594 Tests


CaseIH 2594 tractor photo
1984 - 1988
Row-Crop tractor
Series map:
2394
2594
197.0hp
217.0hp

Note: the CaseIH model 2594 is the same as the J.I. Case 2594. The following data is from the 2594 listing.
Nebraska Tractor Test 1529
2594 fuel use from test 1529
Nebraska Tractor Test 1529
Diesel 24-speed 2WD
May 31 - June 20, 1984
Link: Nebraska Tractor Test 1529 file
PTO performance
Power at rated engine speed182.07 hp
135.8 kW
Fuel use12.0 gal/hour
45.4 l/hour
Drawbar performance
Max power159.64 hp
119.0 kW
Fuel use11.9 gal/hour
45.0 l/hour
Gear 3-4 used for power test.
Max pull16874 lbs
7654 kg
Gear 2-2 used for pull test.
