Minneapolis-Moline GB Tests
|
|
| Tractor Tests | |
| NTTL 545: LP gas 5-speed 2WD | |
| NTTL 547: gasoline 5-speed 2WD | |
| NTTL 568: diesel 5-speed 2WD |
| Nebraska Tractor Test 545 | |||
| |||
| Nebraska Tractor Test 545 | |
| LP gas 5-speed 2WD May 31 - June 7, 1955 Link: Nebraska Tractor Test 545 file | |
| Belt power (max) | 70.55 hp 52.6 kW |
| Belt fuel use (max) | 7.5 gal/hour 28.4 l/hour |
| Drawbar performance | |
| Max power | 62.14 hp 46.3 kW |
| Fuel use | 7.5 gal/hour 28.4 l/hour |
| Gear 3 used for power test. | |
| Max pull | 7094 lbs 3217 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 547 | |||
| |||
| Nebraska Tractor Test 547 | |
| Gasoline 5-speed 2WD June 8 - 15, 1955 Link: Nebraska Tractor Test 547 file | |
| Belt power (max) | 65.64 hp 48.9 kW |
| Belt fuel use (max) | 6.0 gal/hour 22.7 l/hour |
| Drawbar performance | |
| Max power | 46.26 hp 34.5 kW |
| Fuel use | 4.6 gal/hour 17.4 l/hour |
| Gear 3 used for power test. | |
| Max pull | 6718 lbs 3047 kg |
| Gear 1 used for pull test. | |
| Nebraska Tractor Test 568 | |||
| |||
| Nebraska Tractor Test 568 | |
| Diesel 5-speed 2WD November 1 - 7, 1955 Link: Nebraska Tractor Test 568 file | |
| Belt power (max) | 62.78 hp 46.8 kW |
| Belt fuel use (max) | 4.1 gal/hour 15.5 l/hour |
| Drawbar performance | |
| Max power | 63.70 hp 47.5 kW |
| Fuel use | 4.7 gal/hour 17.8 l/hour |
| Gear 3 used for power test. | |
| Max pull | 7333 lbs 3326 kg |
| Gear 1 used for pull test. | |
