Tractors > Massey Ferguson > 1500

Massey Ferguson 1500 Engine



Massey Ferguson 1500 tractor photo
1971 - 1974
Four-wheel Drive (4WD) tractor
Series map:
1500
1800
180.0hp
210.0hp
Engine Detail
Caterpillar 3150
diesel
8-cylinder
liquid-cooled V-8
Displacement573 ci
9.4 L
Bore/Stroke4.50x4.50 inches
114 x 114 mm
Power180 hp
134.2 kW
Air cleanerdry
Compression17:1
Rated RPM3000
Torque386 lb-ft
523.4 Nm
Torque RPM1600
Starter volts12
Oil capacity12 qts
11.4 L
Coolant capacity47.5 qts
45.0 L
Massey Ferguson 1500 Engine
Massey Ferguson 1500 engine image
